Chapter 9
[1]
[3]
5) Shift the connector support plate [2] toward the outside.
- 2 screws [1]
[1]
[1]
6) Remove the internal delivery roller [3].
- 2 E-rings [1]
- 2 bearings [2]
[3]
[2]
[1]
9-26
[2] [1]
F-9-64
F-9-65
[2]
F-9-66
[1]
[2]
F-9-67
9.5.6.3 Points to Note When Mounting the Internal
Delivery Roller
iR5065 / iR 5055 / iR5075 / / /
A harness is found near the end of the internal delivery roller shaft (at the rear
side) and 2 plastic sheets [1] are attached to protect the harness. When
mounting/removing the internal delivery roller, be careful not to remove
these plastic sheets by accident. If removed accidentally, reattach the sheets
back to the initial positions.
[1]
9.5.7 Main Thermistor
9.5.7.1 Before Removing the Main Thermistor/Shutter
Thermistor
iR5065 / iR 5055 / iR5075 / / /
1) Detach the duplexing
12)Reference[Removing the Duplexing Feed Front Cover]
2) Slide out the fixing/feeding unit. (page 9-18)Reference[Removing the
Fixing/Feeding unit]
3) Detach the fixing front cover. (page 10-14)Reference[Removing the
Fixing Front Cover]
4) Detach the fixing/feeding
13)Reference[Removing the Fixing/Feeding Unit Front Cover]
5) Detach the fixing/feeding unit middle cover. (page
13)Reference[Removing the Fixing/Feeding Unit Middle Cover]
6) Detach the fixing upper cover. (page 10-13)Reference[Removing the
Fixing Upper Cover]
7) Remove the fixing drive assembly. (page 10-20)Reference[Removing
the Fixing Drive Assembly]
8) Remove the fixing upper unit. (page 9-19)Reference[Removing the
Fixing Upper Unit]
9) Remove the fixing web. (page 9-31)Reference[Removing the Fixing
Web]
9.5.7.2 Removing the Main Thermistor/Shutter
Thermistor
iR5065 / iR 5055 / iR5075 / / /
1) Remove the bushing [2], and then remove the web unit [3].
- 1 screw [1]
[2]
F-9-68
feed front cover.
(page
unit front cover. (page
0015-5054
0015-7186
10-
10-
10-
0015-5055
