Canon imageRUNNER 5065 series Service Manual page 480

Chapter 16
Code Description
8001 The incoming light voltage is faulty in the presence of light. (trailing edge
sensor)
8002 The incoming light is faulty in the absence of light and voltage. (trailing
edge sensor)
8003 The incoming light voltage is faulty in the presence of light. (horizontal
registration sensor 1)
8004 The incoming light voltage is faulty in the absence of light. (horizontal
registration sensor 1)
8005 The incoming light voltage is faulty in the presence of light. (horizontal
registration sensor 2)
8006 The incoming light voltage is faulty in the absence of light. (horizontal
registration sensor 2)
8007 The incoming light voltage is faulty in the presence of light. (horizontal
registration sensor 3)
8008 The incoming light voltage is faulty in the absence of light. (horizontal
registration sensor 3)
8009 The incoming light voltage is faulty in the presence of light. (horizontal
registration sensor 4)
800A The incoming light voltage is faulty in the absence of light. (horizontal
registration sensor 4)
E593 There is a punch shift motor error. (punch unit)
8001 In the presence of light, the incoming light voltage HP sensor does not go
off.
8002 In the absence of light, the incoming light voltage HP sensor does not go
on.
E5F0 There is a saddle paper positioning error.
0001 The paper positioning plate home position sensor does not go on even when
the paper positioning plate motor has been driven for 1.33 sec.
paper positioning plate motor (M4S), paper positioning plate home
position sensor (PI7S)
0002 The paper positioning plate home position sensor does not go off even
when the paper positioning plate motor has been driven for 1 sec.
paper positioning plate motor (M4S), paper positioning plate home
position sensor (PI7S)
E5F1 There is a saddle paper folding error.
0001 The number of detection pulses of the paper folding motor clock sensor is
lower than a specific value.
paper folding motor (M2S), paper folding motor clock sensor (PI4S)
0002 The state of the paper folding home position sensor does not change even
when the paper folding motor has been driven for 3 sec.
paper folding motor (M2S), paper folding motor clock sensor (PI4S)
E5F2 There is a saddle guide error.
0001 The guide home position sensor does not go on even when the guide motor
has been driven for 0.455 sec.
guide motor (M3S), guide home position sensor (PI13S)
0002 The guide home position sensor does not go off even when the guide motor
has been driven for 1 sec.
guide motor (M3S), guide home position sensor (PI13S)
E5F3 There is a saddle alignment error.
0001 The aligning plate home position sensor does not go on even when the
aligning motor has been driven for 0.5 sec. (if at time of initialization, 1.67
sec)
alignment motor (M5S), aligning plate home position sensor (PI5S)
0002 The aligning plate home position sensor does not go off even when the
aligning motor has been driven for 1 sec.
alignment motor (M5S), aligning plate home position sensor (PI5S)
E5F4 There is a saddle rear stapler error.
0001 The stitching home position sensor does not go on even when the stitching
motor (rear) has been driven in reverse for 0.5 sec or more.
stitching motor (rear, M6S), stitching home position sensor (rear, MS5S)
0002 the stitching home position sensor does not go off even when the stitching
motor (rear) has been driven in normal direction for 0.5 sec or more.
stitching motor (rear, M6S), stitching home position sensor (rear, MS5S)
E5F5 There is a saddle front stapling error.
0001 The stitching home position sensor does not go on even when the stitching
motor (front) has been driven in reverse for 0.5 sec or more.
stitching motor (front, M7S), stitching home position sensor (front, MS7S)
0002 The stitching home position sensor does not go off even when the stitching
motor (front) has been driven in normal direction for 0.5 sec or more.
stitching motor (front, M7S), stitching home position sensor (front, MS7S)
E5F6 There is a saddle butting error.
16-6
Remedy
- turn off and then back on the main power.
- Turn off and the back on the main power.
- Check the paper positioning plate motor (M4S) and the paper positioning
plate home position sensor (PI7S).
- Check the paper folding motor (M2S) and the paper folding motor clock
sensor (PI4S).
- Check the guide motor (M3S) and the guide home position sensor
(PI13S).
- Check the alignment motor (M5S) and the aligning plate home position
sensor (PI5S).
- Check the stitching motor (rear, M6S) and the stitching home position
sensor (rear, MS5S).
- Check the stitching motor (front, M7S) and the stitching home position
sensor (front, MS7S).
