Chapter 17
Sub-item Description
Use it to adjust the leading edge registration.
adjustment range: -50 to 50
REGIST
Use it to adjust the horizontal registration for duplex mode.
adjustment range: -50 to 50
ADJ-REFE
Use it to adjust the registration for manual pickup.
adjustment range: -50 to 50
RG-MF
<CST-ADJ>
Sub-item Description
C3-STMTR Use it to enter the paper width basic value for cassette 3 (STMTR).
adjustment range: 0 to 255
C3-A4R Use it to enter the paper width basic value for cassette 3 (A4R).
adjustment range: 0 to 255
C4-STMTR Use it to enter the paper width basic value for cassette 4 (STMTR).
adjustment range: 0 to 255
C4-A4R Use it to enter the paper width basic value for cassette 4 (A4R).
adjustment range: 0 to 255
MF-A4R Use it to enter the paper width basic value for the manual feed tray (A4R).
adjustment range: 0 to 255
MF-A6R Use it to enter the paper width basic value for the manual feed tray (A6R).
adjustment range: 0 to 255
MF-A4 Use it to enter the paper width basic value for the manual feed tray (A4).
adjustment range: 0 to 255
C3-LVOL Use it to enter the capacity of the cassette 3 (50 sheets).
adjustment range: 0 to 255
C3-HVOL Use it to enter the capacity of the cassette 3 (275 sheets).
adjustment range: 0 to 255
C4-LVOL Use it to enter the capacity of the cassette 4 (50 sheets).
adjustment range: 0 to 255
C4-HVOL Use it to adjust the capacity of the cassette 4 (275 sheets).
adjustment range: 0 to 255
<MISC>
Sub-item Description
ATM Use it to make settings related to the atmospheric pressure of the site of installation.
settings range: 0 to 2 (default: 0)
0: 1 to 0.75 atm (up to elevation of 2500 m)
1: 0.75 to 0.70 atm (elevation between 2500 and 300 m)
2: 0.70 to 0.65 atm (elevation between 300 and 3500 m)

17.4.2 FEEDER

17.4.2.1 FEEDER List

iR5065 / iR 5055 / iR5075 / / /
Sub-item Description
DOCST Use it to adjust the original image leading edge position.
- a higher setting will delay the timing for the image leading edge.
adjustment range: -50 to 50 (unit: 0.1 mm)
LA-SPEED Use it to adjust the original feed speed in feeder stream reading mode.
- a higher setting will increase the speed (i.e., contracts the image).
adjustment range: -30 to 30 (unit: 0.1%)
DOCST2 Adjustment of VYSNC timing on the backside of the feeder at simultaneous double-sided reading.
adjustment range: -50 to 50 [default: 0] (unit: 0.1mm)
LA-SPEED2 Use it to adjust the sub scanning magnification in feeder back stream reading mode for duplex simultaneous reading.(for fine
adjustment of HSYNC length)
adjustment range: -120 to 120 [temporary] (unit: 0.1%)

17.4.3 SORTER

17.4.3.1 SORTER List

iR5065 / iR 5055 / iR5075 / / /
17-24
T-17-27
COPIER > ADJUST > FEED-ADJ
T-17-28
COPIER > ADJUST > CST-ADJ
T-17-29
COPIER > ADJUST > MISC
T-17-30
COPIER > FEEDER > ADJUST
Level
1
1
1
Level
1
1
1
1
1
1
1
1
1
1
1
Level
1
0015-5843
Level
1
1
1
1
0015-5845
