Canon imageRUNNER 5065 series Service Manual page 477

Code Description
0102 The IH current is faulty. (current leakage)
0103 The IH current is faulty. (no current)
0104 There is an IH over-current.
0105 The IH input voltage is too high.
0106 The IH input voltage is too low.
0201 At power-on (or, when IH is at reset), the IH control mechanism is not in
an initial state.
0202 At IH start-up, the IH control enable flag is not set within 1 sec after the
start flag is set.
0203 With IH at rest, the IH control flag is not released.
0204 The 12-V power supply (IH relay) is identified as being off.
0205 At IH start-up, the PWM/ON data is faulty ('0' or 'FFFF')
E005 There is no fixing web/there is an error in the detection of web solenoid connection.
0000 The absence of the fixing web has been detected for 5 sec or more.
0001 At power-on, the connection of the web solenoid is not detected.
0010 The power has been turned off and then back on without resetting the error. - Reset the fixing web counter. (COPIER>COUNTER>MISC>FIX-WEB)
E010 There is a feed motor error.
0000 The FG signal of the feed motor does not arrive for 2 sec or more even
when the feed motor has been turned on.
E012 There is a drum motor error.
0000 The FG signal of the drum motor does snot arrive for 2 sec or more even
when the drum motor has been turned on.
E013 The waste toner pipe is clogged.
0000 The waste toner pipe is identified as being clogged for 4 sec or more.
0010 The power has been turned off and then back on without resetting the error.
E014 There is a fixing motor error.
0000 The Phase lock signal of the fixing motor does not arrive for 2 sec even
when the fixing motor has been turned on.
E020 There is no toner in the developing assembly; there is an error in the detection of developing toner sensor connection; there is an error in the detection
of hopper toner sensor connection
0000 The presence of toner is detected inside the sub hopper and, in addition, the
absence of toner is detected inside developing assembly for 120 sec
continuously even when operation has been under way for the supply of
toner to the developing assembly.
0001 At power-on, the connection of the developing assembly toner sensor is not
detected.
0002 At power-on, the connection of the developing hopper toner sensor is not
detected.
E025 There is a toner feed motor over-current detection error, there is a toner bottle motor connection detection error.
0001 An over-current has been detected in the toner feed motor.
0002 An over-current has been detected in the toner bottle motor.
0003 At power-on, the connection of the toner bottle motor is not detected.
E032 The NE controller counter has malfunctioned.
0001 An open circuit has been detected for the count pulse signal.
E061 There is a potential control error/there is an APC error.
0001 As a result of potential control, the drum surface potential (VL2) of the
background is 200 V or higher (i.e., causing a solid black image).
0002 The primary charging output used at time of printer output and the drum
surface potential after laser output is identified as being 200 V or more (i.e.,
causing a solid black image).
E100 There is a BD error.
0001 A check is made of VLOCK at intervals of 100 msec while the laser is on.
An error will be identified if it is not detected 10 times in sequence.
E102 There is a laser verify error.
0001 The machine model ID that has been read from the laser scanner EEPROM
is not correct.
E110 There is a polygon motor error.
Remedy
- Check the connector for any fault in connection.
- Replace the fixing heater power supply.
- Replace the DC controller PCB.
- Replace the DC controller PCB.
- Replace the fixing web.
- Replace the fixing web length sensor.
- Replace the DC controller PCB.
After correcting the fault, be sure to reset the fixing web counter reading.
(COPIER>COUNTER>MISC>FIX-WEB)
- Check the connector for any fault in connection.
- Replace the solenoid.
- Check the connector for any fault in connection.
- Replace the motor
- Check the connector for any fault in connection.
- Replace the motor.
- Check the connector for any fault in connection.
- Replace the waste toner feedscrew lock detecting switch.
- Replace the waste toner feed unit.
- Replace the DC controller PCB.
- Check the connector for any fault in connection.
- Replace the motor.
- Check the connector of the developing toner sensor for any fault in
connection.
- Replace the developing toner sensor.
- Replace the hopper toner sensor.
- Check the connector for any fault in connection.
- Replace the sensor.
- Check the connector for any fault in connection.
- Replace the sensor.
- Check the connector for any fault in connection.
- Replace the motor.
- Check the connector for any fault in connection.
- Replace the motor.
- Check the connector for any fault in connection.
- Replace the motor.
Turn off the main power, and check for an open circuit in the cable; then,
turn the main power back on.
- Replace the potential sensor unit.
- Replace the laser scanner unit.
- Replace the DC controller PCB.
- Replace the laser scanner unit.
- Replace the DC controller PCB.
Chapter 16
16-3
