Chapter 8
8-bit Timer
Timer 6 Mode Register (TM6MD: 0x0000A1A4) [8-bit Access Register]
bp 7
Flag TM6
CNE
At reset 0
Access R/W
bp Flag
7 TM6CNE
6 TM6LDE
5-3 -
TM6CK2
2-0 TM6CK1
TM6CK0
When the count clock source is set to IOCLK/128, set the TM6IN flag of the external prescaler control
register TMEXPSC8 to "1" and the EXPSCNE flag to " 1".
..
..
VIII - 24 Control Registers
6 5 4 3
TM6 - - -
LDE
0 0 0 0
R/W R R R
Description
Timer operation enable
Timer initialization
-
Count clock source selection
2 1 0
TM6 TM6 TM6
CK2 CK1 CK0
0 0 0
R/W R/W R/W
Set condition
0: Operation disabled
1: Operation enabled
0: Normal operation
1: Initialization
TM6BR value is loaded into TM6BC.
-
000: IOCLK
001: IOCLK/8
010: IOCLK/32
011: Cascading with timer 5
100: Timer 4 underflow
101: Timer 5 underflow
110: Setting prohibited
111: IOCLK/128
When 1/8 IOCLK and 1/32 IOCLK are used, the prescaler control reg-
ister (TM47PSC) should be set.
