MICROCOMPUTER MN103E00 MN103E00 Series Onboard Debugger NOW MAKING Hardware Manual Pub.No.13340-001E In this manual,the description concerning the dedicated interface board is not written. Please refer to the explanation of the interface board in the installation manual for the MN103 in-circuit emulator packed up together.
Page 3
PanaXSeries is a trademark of Matsushita Electric Industrial Co., Ltd. The other corporation names, logotype and product names written in this book are trademarks or registered trademarks of their corresponding corporations. Request for your special attention and precautions in using the technicalinformation and semiconductors described in this book (1) An export permit needs to be obtained from the competent authorities of the Japanese Government if any of the products or technologies described in this book and controlled under the "Foreign Exchange and Foreign...
Checking the Device Take out all the devices from the cartons, and check that all items are present using the check column in the shipping list provided. T he shape of the devices can be changed or an additional item can be included upon special request.
Page 6
Please refer to the following "Connection with the details. TGT(green):Power supply of target board target board" for details. (Side chart 2) (Side chart 1) (Upper chart) Panasonic POWER Pana Series PX-ODB103E MADE IN JAPAN AC Adaptor jack Connection with AC Adaptor...
Page 7
2.2 Trace Unit ( PX-TRS103E ) The MN103E T race Unit is an option debugging unit to operate the trace function by connecting the terminal for the trace of CPU to be debugged with the host computer and the MN103E Onboard Debug Controller. The Trace Unit does not operate alone because the Trace Unit is a function expansion module of the form connected with MN103E Onboard Debug Controller.
Page 8
2.3 Connection of MN103E Onboard Debug Controller and Trace Unit To use the MN103E Trace Unit, connect the attached T race Unit Connection Adaptor with the EXT1 for the MN103E Onboard Debug Controller/the Trace Unit and the EXT2 connector as shown in the figure below.
Connection with host computer The MN103E Onboard Debug Controller/the MN103E Trace Unit is connected with the DOS/V computer and used. The host computer can be connected by two methods, mentioned below. * Connection with printer port * Connection with dedicated interface board 3.1 Connection of MN103E Onboard Debug Controller and Trace Unit Please connect the host interface cable and the power supply (AC Adaptor) as follows to connect the...
Page 10
3.2 Connection with Printer port The MN103E debugging controller has the printer port and the host interface cable to connect the printer port below. This cable is used to connect theMN103E Onboard Debug Controller / Trace unit with the printer port. The connection method is shown in the figure below.
Page 11
Connection with target board * Notice * It is necessary to install a special connector on the target board to connect the MN103E Onboard Debug Controller/the Trace Unit and the target board equipped with the device for debugging. Please refer to the following "Notes when the target board is designed" for this special connector. 4.1 Using MN103E Onboard Debug Controller alone The JTAG cable of 16-wire (8-wire x 2) attached is used to connect the MN103E Onboard Debug Controller and the target board equipped with the device for debugging.
Page 12
4.2 Using MN103E Trace Unit When using MN103E Trace Units in combination with MN103E Onboard Debug Controller,connect to the target board equipped with the device for debugging by the trace cable of 40-wire (20-wire x 2) attached as shown below. When the MN103E trace unit is used, it is unused.
Start procedure When debugging with MN103E Onboard Debug Controller/Trace Unit, operate as following procedure. The connection of MN103E Onboard Debug Controller/Trace Unit and host cmputer and target board is confirmed. The power supply of the MN103E Onboard Debug Controller/the Trace Unit is turned on, and confirm that the MN103E Onboard Debug Controller's POWER lamp (red) lights.
Page 14
Notes in Designing Target Board 6.1 Concerning the connector for the MN103E Onboard Debug Controller/the Trace Unit connection 6.1.1 Connector for MN103E Onboard Debug Controller Connection Please mount the connector like the figure below on the target board when the MN103E Onboard Debug Controller is used alone.
Connector for MN103E Trace Unit connection 6.1.2 Please mount the connector like the figure below on the target board when using MN103E Onboard Debug Controller in combination with MN103E Trace Unit. Please wire this connector as shown in the figure below. straight type right angle type Maker:HIROSE ELECTRIC...
Page 16
6.2 Concerning the wiring of the JTAG scanning chain The MN103E Onboard Debug Controller /the Trace Unit is a device which supports the software debugging by using IEEE1149.1 of MN103E series CPU (alias JTAG). Normally,to test the board where IEEE1149.1 originally aims (boundary scan test), the device corresponding to IEEE1149.1 is connected by one scanning chain on the target board as shown in the figure below.
