Installation

This section describes the installation of the DMP 128 Plus and covers the following topics:
•
•
•
•
•

DMP 128 Plus Models

Model
DMP 128 Plus
DMP 128 Plus C
DMP 128 Plus C V
DMP 128 Plus AT
DMP 128 Plus C AT
DMP 128 Plus C V AT 12x 8 ProDSP Processor with AEC, VoIP and Dante

Mounting

The 1U high, full rack width, 8.5 inch deep DMP 128 Plus mounts in the following manners:
•
•
•
NOTE: To mount the DMP 128 Plus using an Extron mounting kit, see the instructions
DMP 128 Plus Models
Mounting
Rear Panel Features and Cabling
Front Panel Features
Hardware Reset Modes
Description
12x 8 ProDSP Processor
12x 8 ProDSP Processor with Acoustic Echo Cancellation (AEC)
12x 8 ProDSP Processor with AEC and VoIP
12x 8 ProDSP Processor with Dante
12x 8 ProDSP Processor with AEC and Dante
Rack mounting — Attach the DMP 128 Plus to a standard 19-inch rack shelf. The
following Underwriters Laboratories (UL) guidelines pertain to the installation of the
DMP 128 Plus in a rack:
Reduced air flow — Install the equipment in the rack so that the amount of air
•
flow required for safe operation of the equipment is not compromised.
Mechanical loading — Mount the equipment in the racks so that uneven
•
mechanical loading does not create a hazardous condition.
Circuit overloading — When connecting the equipment to the supply circuit,
•
consider the effect that circuit overloading might have on overcurrent protection
and supply wiring. Consider equipment nameplate ratings when addressing this
concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
•
equipment. Pay particular attention to power supply connections other than direct
connections to the branch circuit (such as the use of power strips).
Under-furniture mounting — Mount the DMP 128 Plus under the surface of a desk,
table, or podium.
Free-standing — Attach the four rubber feet provided with the device to the bottom of
the DMP 128 Plus in the four corners and place the unit on furniture as desired.
provided with the kit.
DMP 128 Plus • Installation 4
