Aux Input Dynamics Block

Two dynamics blocks are available for each Aux input. These blocks function the same
as the mic/line input dynamics blocks (see
information on configuring the Aux input dynamics blocks).

Aux Input Ducking Block

One ducking block is available for each Aux input. This block functions the same as the
mic/line input ducking block (see
configuring the Aux input ducking block).

Aux Input Automix Block

One automix block is available for each Aux input. This block functions the same as the
mic/line input automix block (see
configuring the Aux input automix block).

Aux Input Pre-Mixer Gain Block

The Aux input pre-mixer gain block functions the same as the mic/line input pre-mixer gain
block (see
Aux input pre-mixer gain block).

Virtual Returns

Virtual returns receive signal when inputs are routed to the virtual send bus (see
on page 55). Sixteen virtual return channels are available and are labeled
These channels can be used in a number of applications. For example, they can act as an
AEC reference channel or be used for sub-mix processing.
Figure 80.
Input Ducking Block
Input Automix Block
Input Pre-Mixer Gain Block
Virtual Returns Input Panel
Input Dynamics Blocks
on page 38 for information on
on page 40 for information on
on page 42 for information on configuring the
DMP 128 Plus • DSP Configurator Software
on page 32 for
figure 92
through .
