Installation
This section describes the installation of the XMP 240 C AT and covers the following topics:
•
•
•
•
Mounting
The 1U high, half rack width, 9.5 inch deep XMP 240 C AT mounts in the following manners:
•
•
•
NOTE: To mount the XMP 240 C AT using an Extron mounting kit, see the instructions
Mounting
Rear Panel Features and Cabling
Front Panel Features
Hardware Reset Modes
Rack mounting — Attach the XMP 240 C AT to a standard 19-inch rack shelf. The
following Underwriters Laboratories (UL) guidelines pertain to the installation of the
XMP 240 C AT in a rack:
•
Reduced air flow — Install the equipment in the rack so that the amount of air
flow required for safe operation of the equipment is not compromised.
•
Mechanical loading — Mount the equipment in the racks so that uneven
mechanical loading does not create a hazardous condition.
Circuit overloading — When connecting the equipment to the supply circuit,
•
consider the effect that circuit overloading might have on overcurrent protection
and supply wiring. Consider equipment nameplate ratings when addressing this
concern.
•
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to power supply connections other than direct
connections to the branch circuit (such as the use of power strips).
Under-furniture mounting — Mount the XMP 240 C AT under the surface of a desk,
table, or podium.
Free-standing — Attach the four rubber feet provided with the device to the bottom of
the XMP 240 C AT in the four corners and place the unit on furniture as desired.
provided with the kit.
XMP 240 C AT • Installation
