Flexible NC programming
1.1 Variables
Further information (
Initialization during definition
● All or the optionally specified number of array elements are initialized with the specified
● Variables of the FRAME data type cannot be initialized.
Example:
Program code
DEF REAL varName[10]=REP(3.5,4)
Value assignment in program execution
In the case of value assignment in program execution, the rules described above for
definition apply. The following options are also supported:
● Expressions are also permitted as elements in the value list.
● Value assignment starts with the programmed array index. Values can be assigned
Examples:
Program code
DEF REAL varName[10]
varName[5]=REP(4.5,3)
R10=REP(2.4,3)
DEF FRAME FRM[10]
FRM[5] = REP(CTRANS (X,5))
Further information (general)
Value assignments to axial machine data
In principle axial machine data have an array index of the
value assignments to an axial item of machine data using
ignored or not processed.
Example: Value assignment to machine data MD36200 $MA_AX_VELO_LIMIT
$MA_AX_VELO_LIMIT[1,AX1]=SET(1.1, 2.2, 3.3)
52
)
REP
value (constant).
selectively to subarrays.
Is equivalent to:
$MA_AX_VELO_LIMIT[1,AX1] = 1.1
$MA_AX_VELO_LIMIT[2,AX1] = 2.2
$MA_AX_VELO_LIMIT[3,AX1] = 3.3
Comments
; Initialize array definition and array
elements [0] to [3] with value 3.5.
Comments
; Array definition
; Array elements [5] to [7] = 4.5
; R-parameters R10 to R12 = 2.4
; Array definition
; Array elements [5] to [9] = CTRANS(X,5)
data type. In the case of
AXIS
or
SET REP
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
, this array index is
