Diagnostics

Overview

Running Diagnostics

Technical Manuals Online! - http://www.tech-man.com
The 4010 has the capability to run diagnostics of the N2 communication lines,
the IDNet channel, the Network communication lines, and to locate an Earth
Fault between IDNet devices. This section shows how to run the diagnostic
utility on the 4010.
Running diagnostics is the easiest way to ensure proper communication between
the FACP and its various devices. To use the Diagnostics, you must be logged
in at a Level 4. Follow Steps 1 through 3 to run diagnostics on the 4010.
1. From the High-Level Status screen, press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [Diagnostics] is displayed and then
press <ENTER>.
3. Press <NEXT> or <PREVIOUS> to select the desired diagnostic option
and then press <ENTER>.
The Diagnostic options are shown in Figure 10-1.
Top Level Menus
Software
Diagnostics
Revision
Figure 10-1. Diagnostic Options
10-2
Set Time
and Date
•
N2 Communications
•
IDNet Earth Fault Search
•
IDNet Diagnostics
•
Network
Continued on next page
