Configuring List Points

Overview

Configure a List

Technical Manuals Online! - http://www.tech-man.com
This section describes how to configure a List.
Use the following steps to configure a List in the 4010 FACP.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
Please Wait . . .
Fire Alarm Operation Suspended
3. Press <ENTER> to continue.
Press <NEXT> or <PREVIOUS> until <CONFIGURE POINTS> is
4.
displayed and then press <ENTER>.
5. Press <NEXT> or <PREVIOUS> to scroll through your choices until
<LIST> is displayed and then press <ENTER>.
Use <NEXT> or <PREVIOUS> to scroll through your lists until the
6.
desired list is displayed and then press Enter.
Press <NEXT> or <PREVIOUS> to scroll through your list of choices until
7.
the desired option is displayed and then press Enter. Your choices are
shown in Table 6-8.
Function
Add Point (See Note 2)
Delete Point
Delete ALL Points
Edit Point Label (See Notes 1 and 3)
Clear Point Label (See Notes 1 and 3)
Edit Point Type (See Notes 1, 2, and 3)
Notes:
1. This function not allowed for all Lists.
2. For a complete list of your choices for these edit functions, refer
to "Appendix B. Hardware and Pseudo Points."
3. To complete these functions, refer to their appropriate section
in this publication.
Table 6-8. List Configuration Choices
Allows you to add specific point(s) to a List
Allows you to delete specific point(s) from a List
Allows you to delete all points from a List
Allows you to change the 40-Character label of
the List
Blanks the 40-Character Label of the List
Changes the Point Type for the List
6-18
Description
Continued on next page
