Hardware Points,
Master Controller Points
(continued)
Point Type
0-1 R
0-2 R
0-3 R
0-4 R
0-5 R
0-6 R
0-7 R
0-8 U
0-9 U
0-10 U
0-11 U
0-12 U
0-13 R
NAC Card

NAC Card Status Points

Technical Manuals Online! - http://www.tech-man.com
Continued
Table B-1. Master Controller Points
Label
Front Panel Piezo
External N2 Disconnect
Relay
Fire LED
Supervisory LED
Trouble LED
Alarm Silence LED
AC Power LED
User LED 1
User LED 2
User LED 3
User Defined Key 1
User Defined Key 2
LCD Backlight
The NAC (Notification Appliance Circuit) Card is required for all 4010
configurations, and is located at Card Address 1. There are seven hardware
points and eight card status points associated with the NAC card.
The NAC Card has eight card status points associated with it. Table B-2
describes the card status points for the NAC card.
Description
Indicates the status of the Piezo Sounder on the 4010
Master.
Indicates the status of the External N2 Disconnect
Relay. Turns on when no slaves are communicating;
turns off on System Reset.
Status of the front panel Alarm LED.
Status of the front panel Supervisory LED.
Status of the front panel Trouble LED.
Status of the front panel Alarm Silence LED.
Status of the front panel AC Power LED.
This point indicates the status and configuration of the
first user programmable LED on the front panel.
This point indicates the status and configuration of the
second user programmable LED on the front panel.
This point indicates the status and configuration of the
third user programmable LED on the front panel.
This point indicates the status and configuration of the
first user programmable key (in the function menu).
This point indicates the status and configuration of the
second user programmable key (in the function menu).
Indicates the status of the LCD backlight on the front
panel.
B-3
