Configuring 24-Point I/O Points,
Configuring 24-Point Output
Points (continued)
Technical Manuals Online! - http://www.tech-man.com
Continued
Table 6-7. 24-Point Output Point Configuration Choices
Function Description
Edit Device Type Changes the Hardware Device Type of the Point.
Choose Input or Output
Edit Point Type Changes the Software Point Type of the Point. Your
choices for Output points are:
Edit Point Label* Changes the 40-Character Label of the Point
Clear Point Label* Blanks the 40-Character Label of the Point
Edit Mode Changes the Mode of Operation for the Point. Your
choices for modes are:
*This function not allowed for 24-Point Output points.
6-17
•
LAMP (Lamp or LED output)
•
PIEZO (Piezo output)
•
RELAY (Generic relay)
•
RRELAY (Relay on 'til reset)
•
SMPL (SMPL controlled)
•
Fire (Fire alarm LED)
•
Supervisory (Supervisory LED)
•
Trouble (Trouble LED)
•
Disable (Disable LED)
•
On (ON LED)
•
Off (OFF LED)
•
LF (Local fire acknowledge)
•
LS (Local supervisory acknowledge)
•
LT (Local trouble acknowledge)
