Pseudo Points,
4010 System Lists (continued)
L1 General Alarm Monitor Points
L2 Waterflow Alarm Monitor Zones
L3 Sprinkler Supervisory Monitor Zones
L4 Primary Elevator Recall Monitors
L5 Alternate Elevator Recall Monitors
L6 Control Points, Off With Silence
L7 Control Points, Off With Reset
L8 Supervisory Monitor Points
L9 Automatic Suppression Release Points
L10 Suppression Manual Release Points
L11 Suppression Release Abort Points
L12 Suppression Release Output Points

4010 User Lists

Technical Manuals Online! - http://www.tech-man.com
Continued
Table B-22. 4010 System List
The user list pseudo card in the 4010 is at Card Address 23. It has 25 points
available that may be filled by the user for specialized applications. The user
lists may have custom labels assigned to them.
Auto-generated by the panel and not editable. Contains
all fire-alarm monitor points in the system plus the
Manual Evac pseudo. User FIRE digital pseudos are not
auto generated here.
Auto-generated by the panel and not editable. Contains
all waterflow-type monitor points (WSO).
Auto-generated by the panel and not editable. Contains
all sprinkler-type monitor points (SO).
Filled by the user. When in fire state, will activate the
primary elevator recall function.
Filled by the user. When in fire state, will activate the
alternate elevator recall function.
Filled by the user. Turns on when L1 is in FIRE detect,
turns off with alarm silence.
Filled by the user. Turns on when L1 is in FIRE detect,
turns off with completed system reset.
Auto-generated by the system - may be edited.
Contains all Supervisory type monitor points.
Filled by the user. When in fire state, causes L12 to
activate after automatic release delay timer expires.
Filled by the user. When in the fire state, causes L 12 to
activate after manual release delay timer expires.
Filled by the user. When in the supervisory state,
causes the suppression release sequence to abort.
Filled by the user. Activated by the panel when the
suppression release algorithm completes.
