TrueAlert Non-Addressable Horn Operation
Introduction
Setting the TrueAlert Non-
Addressable Horn Option
Technical Manuals Online! - http://www.tech-man.com
The TrueAlert Non-Addressable Horn Operation option defines the way in which
TrueAlert Horns function when activated. The default function is Temporal.
Use the following steps to set the TrueAlert Non-Addressable Horn system option.
1.
Press <MENU>.
2.
Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
3.
Press <ENTER> to continue.
4.
Press <NEXT> or <PREVIOUS> until <SYSTEM OPTIONS> is
displayed and then press <ENTER>.
5.
Press <NEXT> or <PREVIOUS> to scroll through your choices until
<QALERT HORN OPERATION> is displayed and then press <ENTER>.
Press <NEXT> or <PREVIOUS> to choose the settings shown in Table
6.
7-2.
Table 7-2. Audible and Visual NAC Operation Settings
System Option
TrueAlert Non-Addressable
Horn Operation
* Default Settings
Follow the prompts to confirm this action.
7-10
Choices
Choose:
•
Temporal*
•
Steady
•
Slow March
