Custom Control Programming,
Fields 3 & 4 (Continued)

Output Side (THEN)

Technical Manuals Online! - http://www.tech-man.com
Field A
SECOND
[ALL] [FIRE ACK] [23-01]
STAGE FIELDS
Two-stage Input
Condition
Specifier
Example: When all points in List 23-01 are in the condition of FIRE
DELAY CNST
When using the input condition qualifier DELAY CNST, and the input statement
is true, the output action is delayed for a specified amount of time (in seconds).
Note: The input must be true for the entire delay time specified.
SECOND
[DELAY CNST] [21-05] [00020]
STAGE FIELDS
Two-stage Input
Condition
Specifier
Each output statement is made up of three fields.
Field 1
OUTPUT
[Hold On]
STATEMENT
Continued
Field B
Condition
Figure 8-30
ACK, then execute the output.
Field A
Point
Figure 8-31
Field 2
[21-02]
Action
Specifier for
Field 2
Figure 8-32
8-24
Field C
List Point
Field B
Field C
Specified
Delay Time
Field 3
[9,9]
Point Priority
Continued on next page
