Custom Control Programming,
Fields 3 & 4 (Continued)
Technical Manuals Online! - http://www.tech-man.com
Continued
ON/CODE and OFF
When using the input condition qualifier ON/CODE (On Coding), a statement is
true when the point indicated in Field 4 is On or Coding. Field 4 choices for the
ON/CODE qualifier are:
•
CPU Card Points
•
System Card Points
•
Power Supply Points
•
Digital Pseudo Points
•
Analog Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is
OFF.
Field 1
FIRST
[ ]
STATEMENT
Example: The condition of 3-01 is ON/CODE. The input of the equation
remains true until the point indicated in Field 4 is OFF.
When using the input condition qualifier OFF, a statement is true when the point
indicated in Field 4 is OFF. Field 4 choices for the OFF qualifier are:
•
CPU Card Points
•
System Card Points
•
Power Supply Points
•
Digital Pseudo Points
•
Analog Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is ON
or Coding.
Field 1
FIRST
[ ]
STATEMENT
Example: The condition of 3-01 is OFF. The input of the equation remains
true until the point indicated in Field 4 is ON or Coding.
Field 3
Field 2
[ ] [ON/CODE]
Figure 8-26
Field 2 Field 3
[ ] [OFF]
Figure 8-27
8-21
Field 4
[3-01]
Field 4
[3-01]
