This section describes how to add, delete, or modify cards in a 4010 FACP. Be
aware of the following configuration rules when adding, deleting, or modifying
cards.
•
Cards 1 through 3 and 17 through 23 cannot be deleted.
•
Certain cards are mutually exclusive. For example:
-
One 4120 Network Card or One DACT is allowed.
-
One Dual RS232 Card or One RS232/Modem is allowed.
•
The City Circuit card and Expansion Power Supply are enabled via the
System Options menu. Refer to Chapter 7 for information on doing this.
•
The DACT and Network cards are programmed and added to the 4010
FACP via the 4010 PC Programming tool.
Use the following steps to add a card to the 4010 FACP.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
Please Wait . . .
Fire Alarm Operation Suspended
3. Press <ENTER> to continue.
4. Press <NEXT> or <PREVIOUS> until <CONFIGURE CARDS> is
displayed and then press <ENTER>.
5. Press <NEXT> or <PREVIOUS> until <ADD 4010 CARD> is displayed.
6. Press <NEXT> or <PREVIOUS> to scroll through the choices listed
below.
•
RS232 Card (Card Address 4)
•
Modem Card (Card Address 4)
•
24IO Card (Card Address 9 through 14)
•
LCD (Card Address 9 through 14)
7. Once the desired card is displayed, press Enter. The RS232 and Modem
cards are automatically set to card address 4. Follow the prompts to confirm
this action.
