Simplex 4010 Installing And Operating Insructions page 174

Hardware Points,
NAC Card Status Points
(continued)
Point
1-CS 1
1-CS2
1-CS3
1-CS4
1 -CS5
1-CS6
1-CS7
1-CS8
NAC Card Points
Technical Manuals Online! - http://www.tech-man.com
Continued
Table B-2. Card Status Points for NAC Card
Label
Missing Card
Wrong Card
NACs 1 & 2 Class A
NACs 3 & 4 Class A
NAC 1 Signal Power
NAC 2 Signal Power
NAC 3 Signal Power
NAC 4 Signal Power
The NAC has seven hardware points associated with it. Of the seven hardware
points, six are points which may be programmed by the user. The other point is
the City Circuit point which is not available for programming or viewing by the
user. The following table is a list of the points on the NAC card. The type field
denotes which class the point falls into (S=System point that is not available to
the user for viewing or programming, U=User Configurable Points).
Table B-3. System and User Points of NAC Card
Point Type Label (default)
1-1 U NAC Circuit: SIG 1
1-2 U NAC Circuit: SIG 2
1-3 U NAC Circuit: SIG 3
1-4 U NAC Circuit: SIG 4
1-5 U AUX Circuit: AUX 1
1-6 U AUX Circuit: AUX 2
1-7 S City Circuit
This trouble indicates that the NAC card is not communicating
with the master.
This trouble indicates that the card returned a card type as
something other than a NAC card type.
NAC 1 and 2 Class A card not inserted trouble. Only occurs if
circuits are configured with NACA device type.
NAC 3 and 4 Class A card not inserted trouble. Only occurs if
circuits are configured with NACA device type.
Indicates a signal power trouble for NAC 1.
Indicates a signal power trouble for NAC2.
Indicates a signal power trouble for NAC3.
Indicates a signal power trouble for NAC4.
NAC card Signal 1 status and configuration.
NAC card Signal 2 status and configuration.
NAC card Signal 3 status and configuration.
NAC card Signal 4 status and configuration.
NAC card Relay 1 status and configuration.
NAC card Relay 2 status and configuration.
Interface 4010 City Module.
B-4
Description
Description
Continued on next page
