Analog Pseudo Points

4010 System Analog Pseudos

Point
A1 Fire Count
A2 Supervisory Count
A3 Trouble Count
A4 System Startup
A5 Almost Dirty Device Count
A6 Dirty Device Count
A7 Excessively Dirty Device Count
A8 Current Year
A9 Current Month
A10 Current Day of Month
A11 Current Hour
A12 Current Minute

4010 User Analog Pseudos

Technical Manuals Online! - http://www.tech-man.com
Continued
Analog pseudo points exist as counters or timers in the 4010 system. SMPL
delay and cycle equations may be written referencing the user Analog pseudo
points on the output side (for delay/cycle operations). Each analog point may
contain a value from 0-65,535 and the point is considered ON when the value is
non-zero. For delay and cycle purposes, the maximum allowable value gives a
real-time range of just over 18 hours. There are two analog pseudo cards in the
4010 system - one reserved for system analogs, and one reserved for user points.
The 4010 system has one analog pseudo card reserved for system use at Card
Address 20. It contains a total of 25 points. At present, only the first seven are
used but the remainder are reserved for future expansion.
Table B-21. 4010 System Analog Pseudos
Label
The user analog pseudo card in the 4010 is at Card Address 21. It has 25 points
available for specialized applications programming. The analog user pseudos
can have custom labels assigned to them.
Description
Number of fire alarms active in system.
Number of supervisory alarms active in system.
Number of troubles active in system.
Pulsed for one poll cycle during system startup.
Total number of devices that have an almost dirty
status (not necessarily a trouble).
Total number of devices that are in Dirty Trouble.
Total number of devices that are in Excessively
Dirty Trouble.
