Hardware Points,
Network Points (continued)
Point Label
NetPt1 None
NetPt2 None
NetPt3 None
↓
↓
NetPt510 None
NetPt511 None

24I/O Card

24I/O Card Status Points

Point
Card-CS1* Missing Card
Card-CS2 Wrong Card
*CS = Card Status
Technical Manuals Online! - http://www.tech-man.com
Continued
Table B-13. Points That May Be Configured on Network Card
This point is the Network Common Trouble Point. This point is public on the
network.
This point contains the Network Type, Class, Destination, and Reference for the
second network public point.
This point contains the Network Type, Class, Destination, and Reference for the
third network public point.
This point contains the Network Type, Class, Destination, and Reference for the
510th network public point.
This point contains the Network Type, Class, Destination, and Reference for the
511th network public point.
The 4010 can have up to six annunciator cards added to the system. One of
these cards is the 24I/O card. The 24I/O card can reside at addresses 9 through
14. There are 24 hardware points and two card status points associated with the
24I/O card.
The 24I/O Card has two card status points associated with it. The following
table describes the card status points for the 24I/O card.
Table B-14. Status Points on the 24I/O Card
Label
This trouble indicates that the card is not communicating with the master.
This trouble indicates that the card returned a card type as something other
than an 24I/O card type.
Description
Description
B-11
