Diagnostics,

Diagnostic Options

N2 Comm Diagnostics

Test Message Counts

IDNet Diagnostics

Technical Manuals Online! - http://www.tech-man.com
Continued
Once a diagnostic option is selected, you can set the options by pressing
<NEXT> or <PREVIOUS> to scroll through the choices shown in Table 10-1.
Diagnostic Option
N2 Comm
IDNet Earth Fault Search
IDNet Diagnostics
Network
Use the N2 Comms Diagnostics to check for noisy N2 comm lines and other N2
comm errors. The screen in Figure 10-2 shows a typical N2 Communication
Diagnostic screen. This screen informs you of the amount of messages sent, the
amount of message retries and the amount of card failures. Note that these
tallies are only kept while diagnostics are active.
Card Address
4010 Card 1, 4010 NAC/Relay Card
Msgs Sent=0
Figure 10-2. N2 Communication Diagnostic Screen
Pressing <NEXT> or <PREVIOUS>scrolls through the available cards that are
communicating on the N2 lines and displays that card's N2 diagnostic information.
Pressing <ENTER> (while a particular card's information is displayed) prompts
you to press <ENTER> again to clear the message counts for that card.
Duplicate Devices
To detect devices set to the same address you can activate the IDNet Diagnostics
- Duplicate Device option. Once activated, there is a trouble in the panel
indicating that you have activated the option. The two devices set to the same
address then come in as a duplicate device trouble for that address.
Acknowledge the trouble and view the point information to determine the
address that the devices are set to and correct the problem.
Table 10-1. Diagnostic Options
Settings
Choose On or Off
Choose On or Off
Choose:
•
IDNet Weak Answer (On/Off)
•
IDNet Duplicate Device (On/Off)
Choose:
•
Node Number (displays the
current node number for the
4010)
•
Topology
•
Attendance
Retries=0
10-3
Fails=0
Continued on next page
