Configuring Digital and Analog Pseudo Points,
Configuring Digital Pseudo
Points (continued)
Configuring Analog Pseudo
Points
Technical Manuals Online! - http://www.tech-man.com
Table 6-4. Digital Pseudo Point Configuration Choices
Function Description
Edit Device Type Changes the Hardware Device Type of the Point
(See Note 1)
Edit Point Type Changes the Software Point Type of the Point.
(See Notes 2) Your choices are:
Edit Point Label Changes the 40-Character Label of the Point
(See Note 2)
Clear Point Label Blanks the 40-Character Label of the Point
(See Note 2)
Edit Mode Changes the Mode of Operation for the Point
(See Note 1)
Notes:
1. This function not allowed for Digital Pseudo points.
2. To complete these functions, refer to their appropriate section
in this publication.
This section describes how to configure analog pseudo points A27 through A50.
A1 through A26 are system points and cannot be edited. Use the following
information to configure analog pseudo points in a 4010 FACP.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
Please Wait . . .
Fire Alarm Operation Suspended
3. Press <ENTER> to continue.
6-12
Continued
•
Utility Point
•
Fire Point
•
Trouble Point
•
Supervisory
Continued on next page
