Hardware Points,

Power Supply Card

Power Supply Card Status
Points
Point
2-CS1 Missing Card
2-CS2 Wrong Card

Power Supply Points

Technical Manuals Online! - http://www.tech-man.com
Continued
The Power Supply Card is required for all 4010 configurations, and is located at
Card Address 2. There are nine hardware points and two card status points
associated with the Power Supply card.
The Power Card has two card status points associated with it. The following
table describes the card status points for the Power Supply card.
Table B-4. Card Status Points for Power Supply Card
Label
This trouble indicates that the Power Supply card is not communicating
with the master.
This trouble indicates that the card returned a card type as something
other than a Power Supply card type.
The Power Supply card has nine hardware points associated with it. All of the
Power Supply points are system points that cannot be modified by the user.
Table B-5 displays a list of the points on the Power Supply card.
Description
B-5
Continued on next page
