Custom Control Programming,
Fields 3 & 4 (Continued)
Technical Manuals Online! - http://www.tech-man.com
Continued
TBL
When using the input condition qualifier TBL (Trouble), a statement is true
when the point indicated in Field 4 is in trouble. Field 4 choices for the TBL
qualifier are:
•
CPU Card Points
•
System Card Points
•
Power Supply Points
•
Digital Pseudo Points
Note:
The statement holds true until the point indicated in Field 4 not in
trouble.
Field 1
FIRST
STATEMENT
[
]
Example: The condition of 3-01 is TBL. The input of the equation remains
true until the point indicated in Field 4 is not in trouble.
TBL ACK
When using the input condition qualifier TBL ACK (Trouble Acknowledge), a
statement is true when the point indicated in Field 4 is in trouble and requires an
acknowledge. Field 4 choices for the TBL ACK qualifier are:
•
CPU Card Points
•
System Card Points
•
Power Supply Points
•
Digital Pseudo Points
Note:
The statement holds true until the point indicated in Field 4 (in
trouble) is Acknowledged.
Field 1
FIRST
[
]
STATEMENT
Example: The condition of 3-01 is TBL ACK. The input of the equation
remains true until the point indicated in Field 4 is acknowledged.
Field 2
Field 3
[
]
[TBL]
Figure 8-24
Field 2
Field 3
[
]
[TBL ACK]
Figure 8-25
8-20
Field 4
[3-01]
Field 4
[3-01]
Continued on next page
