DACT Card

DACT Card Status Points

Point
8-CS1 Missing Card
8-CS2 Wrong Card
8-CS3 Central Station
8-CS4 Phone Line 1
8-CS5 Phone Line 2
8-CS6 Program Checksum
8-CS7 DB Version
Mismatch

SDACT Points

Technical Manuals Online! - http://www.tech-man.com
Continued
Point Label
4-1 None
4-2 None
The DACT card is an optional card that may be added to the 4010 system. The
DACT card is mutually exclusive with the Network card, and if configured, must
reside at Card Address 8. There is one hardware point and seven card status
points associated with the DACT card.
The DACT Card has seven card status points associated with it. The following
table describes the card status points for the DACT card.
Table B-10. Card Status Points for SDACT Card
Label
This trouble indicates that the card is not communicating with the
master.
This trouble indicates that the card returned a card type as something
other than an DACT card type.
This trouble indicates that communication was lost with the Central
Station.
This trouble indicates that Phone Line 1 has been disconnected.
This trouble indicates that Phone Line 2 has been disconnected.
This trouble indicates that the on board DACT card checksum test has
failed.
This trouble indicates that the configuration loaded on the DACT card
differs from the configuration on the master.
The SDACT card has one hardware point associated with it. The point does not
have a label, because it cannot be viewed from the front panel. Table B-11
describes the point on the SDACT card.
Table B-9. Points on the RS232/Modem Cards
Description
Port A point. Default to unsupervised 80 character
Printer port.
Port B point. Default to command line port.
Description
B-9
Continued on next page
