Hardware Points,
Power Supply Points
(continued)
Point
2-1 AC Power
2-2 Positive Earth Ground
2-3 Negative Earth Ground
2-4 Expansion Power Supply
2-5 Expansion Power Supply
Battery
2-6 Battery Low
2-7 Battery Depleted or
Disconnected
2-8 Battery Low Cutout
2-9 Battery Charger

IDNet Card

IDNet Card Status Points

Technical Manuals Online! - http://www.tech-man.com
Continued
Table B-5. Points on the Power Supply Card
Label
This trouble point will indicate that the AC line voltage is too low for
proper system operation.
This trouble point indicates that there is a fault condition between
+24V and Earth.
This trouble point indicates that there is a fault condition between 0V
and Earth.
This trouble point indicates Expansion Power Supply trouble. Only
occurs if expansion supply is configured.
This trouble point indicates Expansion Power Supply AUX Battery
Power trouble. Only occurs if expansion supply is configured.
This trouble point indicates that the battery has a voltage less than
22.8V.
This trouble point indicates that the battery has a voltage less than
19.5V.
This trouble point indicates that AC Power has been lost and the
batteries have reached a depleted state, the system shuts off.
This utility point indicates the status of the battery charger (on/off).
The IDNet Card is required for all 4010 configurations, and is located at Card
Address 3. The IDNet Card defaults to a configuration with no hardware points
(devices). However, up to 250 devices may be programmed for the IDNet Card.
The IDNet Card also includes eight card status points.
The IDNet Card has eight card status points associated with it. Table B-6
describes the card status points for the IDNet card.
Description
B-6
