Software Point Types,
Signal Point Types
Technical Manuals Online! - http://www.tech-man.com
Continued
Every 4010 has four Notification Appliance (signal) points. The default
configuration is SIG1 & SIG2 "on 'til silence" (point type = SSIGNAL) and
SIG3 & SIG4 "on 'til reset" (point type = RSIGNAL).
Table A-6 lists the signal point types and their descriptions.
Table A-6. Signal Point Types
Point Type Description
SIGNAL Generic signal (no default operation)
SSIGNAL Alarm signal - on 'til silence (temporal coded)
RSIGNAL Alarm signal - on 'til reset
SVISUAL Visual - on 'til silence
RVISUAL Visual - on 'til reset
SWATER Waterflow signal - on 'til silence
RWATER Waterflow signal - on 'til reset
SUPV Sprinkler supervisory signal - on 'til ack
SUPREL Suppression (agent discharge) release output
PRIMARY Elevator capture - primary
ALTERN Elevator capture - alternate
AHUR AHU on/off relay - single relay control
AHUO AHU on relay - dual relay control
AHUF AHU off relay - dual relay control
DHOLDER Doorholder control
TSIGNAL Trouble/supervisory signal - on 'til clear
BSIGNAL Trouble/supervisory "bell" signal - on 'til acknowledged
RELAY Generic Relay
A-6
Continued on next page
