Configuring 24-Point I/O Points,
Configuring 24-Point Output
Points
Technical Manuals Online! - http://www.tech-man.com
Continued
Use the following steps to configure output points on the 24-Point I/O card.
1.
Press <MENU>.
2.
Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
Please Wait . . .
Fire Alarm Operation Suspended
3.
Press <ENTER> to continue.
4.
Press <NEXT> or <PREVIOUS> until <CONFIGURE POINTS> is
displayed and then press <ENTER>.
Press <NEXT> or <PREVIOUS> to scroll through your choices until <24
5.
IO OUTPUTS> is displayed and then press <ENTER>.
6.
Use <NEXT> or <PREVIOUS> to scroll through your points until the
desired point is displayed and then press Enter.
7.
Press <NEXT> or <PREVIOUS> to scroll through your list of choices until
the desired option is displayed and then press Enter. Your options are
shown in Table 6-7.
6-16
Continued on next page
