Ricoh D009 Service Manual page 521

Solenoid
Saddle Stitch Hold
6145 19
Solenoid
Stack Junction
6145 20 Gate Open/Close
Motor
Trailing Edge
6145 21 Fence Moving
Motor
Saddle Stitch
6145 22
Staple Motor: Front
Saddle Stitch
6145 23
Staple Motor: Rear
6145 24 Folder Plate Motor
6145 25 Folder Roller Motor Fold Roller Motor
Drive Roller
6145 26
Oscillating Motor
6145 27 Punch Motor
Punch Moving
6145 28
Motor
Punch Registration
6145 29
Detection Motor
Exit Jogger Motor:
6145 30
Front
Exit Jogger Motor:
6145 31
Rear
Exit Jogger
6145 32
Release Motor
SM
Booklet Pressure Roller Solenoid
Stack Junction Gate Motor
Fold Unit Bottom Fence Lift Motor
Booklet Stapler EH185R: Front
Booklet Stapler EH185R: Rear
Fold Plate Motor
Positioning Roller Motor
Punch Drive Motor
Punch Movement Motor
Paper Position Sensor Slide Motor
-
-
-
5-235
Output Check -2
D009/D011/D012/D013
