(tx mode: Internal)
Bit 1: 0, Bit 0: 0 = None
Bit 1: 0, Bit 0: 1 = Low
Bit 1: 1, Bit 0: 0 = Medium
Bit 1: 1, Bit 0: 1 = High
PSTN cable equalizer
(rx mode: Internal)
Bit 3: 0, Bit 2: 0 = None
2-3
Bit 3: 0, Bit 2: 1 = Low
Bit 3: 1, Bit 2: 0 = Medium
Bit 3: 1, Bit 2: 1 = High
PSTN cable equalizer
(V.8/V.17 rx mode: External)
4
0: Disabled
1: Enabled
5 Not used
Parameter selection for dial
tone detection
6
0: Normal parameter
1: Specific parameter
SM
frequencies because of the length of wire between
the modem and the telephone exchange.
Use the dedicated transmission parameters for
specific receivers.
Also, try using the cable equalizer if one or more of
the following symptoms occurs.
Communication error
Modem rate fallback occurs frequently.
This setting is not effective in V.34
communications.
Use a higher setting if there is signal loss at higher
frequencies because of the length of wire between
the modem and the telephone exchange.
Also, try using the cable equalizer if one or more of
the following symptoms occurs.
Communication error with error codes such as
0-20, 0-23, etc.
Modem rate fallback occurs frequently.
This setting is not effective in V.34
communications.
Keep this bit at "1".
Do not change the settings.
0: This uses the fixed table in the ROM for dial tone
detection.
1: This uses the specific parameter adjusted with
SRAM (69ECBEH - 69ECDEH). Select this if the
dial tone cannot be detected when the "Normal
parameter: 0" is selected.
