MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
4 Common Administrative Procedures
Extensions
Auxiliary Equipment
The procedures in this section describe the steps needed to perform the following:
Identify the line/trunk jacks used for Music on Hold, loudspeaker paging,
and maintenance alarms
Identify the extension jacks used for fax, MERLIN MAIL, Voice Messaging
System, Automated Attendant, and AUDIX Voice Power

Music On Hold

Use this procedure to identify the line/trunk jack reserved for connection of a
music source, such as a radio, tape player, or stereo system.
If you use equipment that rebroadcasts music or other copyrighted materials, you
may be required to obtain a copyright license from and pay license fees to a third
party [such as the American Society of Composers, Artists, and Producers
(ASCAP) or Broadcast Music Incorporated (BMI)]. Magic on Hold requires no
such license and can be purchased from your Lucent Technologies dealer.
Only one Music on Hold line/trunk jack is allowed per system.
You cannot assign the line/trunk identified for Music on Hold to a line/trunk pool. If
the line/trunk is currently assigned to a pool, you must remove it before you
program this option.
You cannot assign the line/trunk identified for use with Music on Hold to a button
on any extension or as a Remote Access trunk, and you cannot use the line/trunk
jack identified for Music on Hold for a loudspeaker paging system or maintenance
alarm.
In Release 6.0 and later systems, each system in a network must have its own
music source. A music source connected to a networked switch cannot be used
by the local system.
Summary: Music on Hold
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
System Manager
All, but in Hybrid/PBX mode the line/trunk designated for
Music on Hold cannot be assigned to a line/trunk pool.
System idle
Form 2c, System Numbering: Line/Trunk Jacks
Not Applicable
Line/trunk number
4
4
4
Issue 1
February 1998
Page 4-260
