Lucent Technologies MERLIN LEGEND Release 6.0 System Programming Manual page 772

MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
4 Common Administrative Procedures
Optional Group Features
Group Coverage Member Assignments
Use this procedure to assign or remove an extension from a coverage group. A
coverage group is a group of senders. Coverage is an arrangement in which calls
from a group of senders are redirected to one or more receivers.
NOTE: NOTE: NOTE:
This procedure assigns senders . Before you begin, make certain that the
receivers for the coverage group are also programmed. Receivers can be
assigned through individual or centralized telephone programming. You can
also use the Integrated Solution III/IV feature, Integrated Administration, to
assign coverage receivers. See Chapter 5, "Centralized Telephone
Programming," for information about the appropriate centralized
programming procedure.
A maximum of 30 coverage groups are allowed, each with an unlimited number of
members. Up to eight receivers can be assigned per coverage group.
An extension can be a sender in only one group; it can be a receiver for more than
one coverage group. A calling group can be assigned as a receiver for a coverage
group (see
the QCC queue can be a receiver for up to 30 coverage groups. See "QCC
Operator to Receive Calls" on page 4–58.
If the sender's extension has one or more personal lines assigned, the sender can
be assigned as the principal user so that calls received on the personal line are
sent to receivers programmed for Individual or Group Coverage. See
User for Personal Line" on page 51.
To reassign an extension to a new coverage group, just make the assignment; the
extension is automatically removed from its old group.
Summary: Group Coverage Member
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
"Group Coverage Receiver" on page
Assignments4
System Manager
All
Not required
Form 7c, Group Coverage
Not applicable
Extension numbers
Yes
No
4
–309). In Hybrid/PBX mode only,
Issue 1
February 1998
Page 4-302
"Principal
