MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
4 Common Administrative Procedures
Optional Extension Features
ARS Restriction Level For Extensions
Use this procedure to assign an ARS restriction level to an extension. Only
outgoing calls are affected; users can receive inside, local, and toll calls on
restricted extensions and can join any type of call in progress. In order to use a
route, a caller at an extension must have a Restriction Level that is equal to or
greater than the Facility Restriction Level (FRL) for the route. The restriction level
assigned to extensions is opposite to the FRL assigned to routes, where 0 is the
most and 6 is the least restrictive.
In Release 6.0 and later systems, FRLs assigned to extensions apply not only to
ARS calls but also to calls for non-local dial plan extensions connected by private
trunks to your local system. For this reason, use care in assigning FRLs both to
extensions and to UDP routes. For example, if a user must be restricted from toll
calls on your local system, you may need to plan UDP routes' FRLs to allow the
user to reach necessary non-local dial plan extensions. For details, see
(Uniform Dial Plan) Routing" on page
Summary: Assigning ARS Restriction Level
for an Extension
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
–401.
System Manager
Hybrid/PBX only
Not required
Form 4b, Analog Multiline Telephone
Form 4d, MLX Telephone
Form 4e, MFM Adjunct: MLX Telephone
Form 4f, Tip/Ring Equipment
Form 5a, Direct-Line Console (DLC): Analog
Form 5b, Direct-Line Console (DLC): Digital
Form 5c, MFM Adjunct: DLC
Form 6g, Call Restriction Assignments and Lists
3 (ports assigned as VMI Generic or VMI Integrated are
maximally restricted with an FRL of 0)
0-6, (0 is most restrictive and 6 is least restrictive)
No
No
More
È  È
Drop Dial restriction level
Type ext. no.
Type restriction level
4
4
Dial ext. no.
 U
 Ç
Issue 1
February 1998
Page 4-282
"UDP

+
