4 Common Administrative Procedures
Memory Card
Inserting the Card
To insert the card, hold the card with the Lucent logo facing up and the arrow
pointing toward the slot. See
card into the slot on the processor module.
Figure 4–5.
Figure 4–5
PROCESSOR
MODULE
Push in
to remove
Memory
Card

Inserting the Memory Card

4
for the proper way to insert the memory
Error/Status Code
Display
PCMCIA
Interface Slot
IN S E R
T
C O P
Y R IG
A L L H T ©
R IG 1 9 9
H T S 3 A T
R E S & T
E R V
E D
Memory
Card
Alarm Status
LED
