MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
4 Common Administrative Procedures
Memory Card
Memory Card
A PCMCIA (Personal Computer Memory Card International Association) interface
slot is present on the processor module. The slot is a standard interface through
which information can be added to or obtained from the system using a memory
card. The PCMCIA interface slot accepts one memory card at a time.
This section covers the following memory card functions:
Memory Card Formatting
Restore
Summary information is included for the following procedures:
Backup
Automatic Backup
See "Backup" on page –282 for details about backup and automatic backup.
Card Types
The types of memory cards are described below. The card type is identified by a
preprinted, color-coded label.
Upgrade Card. This card is used for MERLIN LEGEND Communication
System software upgrades. The upgrade can be performed by the system
manager using the memory card and the
main menu. See Maintenance and Troubleshooting for information about
this feature.
This card is identified by an orange label with black lettering.
Translation Card. The backup and restore procedures previously
available to system managers through SPM (using the PC and floppy
disks) can now be performed using the memory card and the new
permits you to set the system to perform automatic backups to the memory
card on a daily or weekly basis. See
on page –447
This card is identified by a white label with black lettering.
Forced Installation. For use by qualified service technicians only, this card
is used when the system software has been corrupted and a re-installation
must be done at the customer site. The use of the card for forced
installation is reserved for emergency situations in which the system
software on the processor module has been damaged.
This card is identified by an orange label with black lettering. In addition,
black stripes are present on the card to distinguish it from an upgrade card.
option on the System menu. A new automatic backup feature
for more information.
4
4
option on the SPM
"Backup" on page –445
Issue 1
February 1998
Page 4-440
and "Restore"
