MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
4 Programming Procedures
PRI Facilities
Dial Plan Routing
Dial plan routing provides a way to route incoming calls on a "per B-channel
group" basis. An incoming call is routed by matching the incoming number (by
service, number of digits, and pattern) and then optionally deleting and/or adding
digits to direct the call to a specific endpoint. A service must be specified; the
number of digits and pattern are optional. For example, you can specify that calls
received from a particular area code should be routed to the specific individual or
group responsible for accounts in that area.
Dial plan routing is available in Hybrid/PBX mode only. Key systems route
incoming calls on a per-line basis.
In Release 4.2 and later, you can specify the following additional services:
MCI Toll Services available for a DMS-250 or DEX600E switch type:
Local exchange carrier services available for a DMS-100 switch type:
NOTES:
1. You can enter a service not shown on the Network Service screen by
2. Dial plan routing does not affect PRI tandem trunks connected to slots
3. You must program a service before you program any other Dial Plan
— MCI PRISM
— MCI Vnet
— MCI 800
— MCI 900
— DMS Private
— DMS INWATS
— DMS OUTWATS
— DMS FX (foreign exchange)
— DMS Tie Trunk
using the 5-digit binary code that represents the service in the Network
Facilities Information Element of ISDN PRI layer 3 signaling protocol.
Contact your service provider for more information about the codes and
see "Miscellaneous Procedure" within the following procedure.
with switch types of LEGEND-Network or LEGEND-PBX. See
Type" on page 4–166
Routing function. If you have not programmed a service, complete the
procedure below for the Tr…‰vpr option and then repeat the procedure
for each optional function that you want to program.
4
for details.
Issue 1
February 1998
Page 4-206
"Switch
