4 Common Administrative Procedures
UDP (Uniform Dial Plan) Routing
UDP (Uniform Dial Plan) Routing
This section includes programming procedures for assigning Uniform Dial Plan
(UDP) routing, available for Hybrid/PBX mode in Release 6.0 and later systems
only.
UDP routing is very similar to ARS, except that it is slightly simpler. UDP routing
allows system users to reach non-local extensions at a remote DEFINITY or
MERLIN LEGEND Communications System that is networked to your system.
Users simply dial the non-local extension number as they would an inside
extension number. Then UDP routing associates the dialed extension number
with one of up to 20 programmed patterns. For each pattern you can specify up to
four routes. For each route, you specify a pool dial-out code. Then you can
program Facility Restriction Levels (FRLs), absorbed digits, added digits, and
voice and/or data capability.
NOTE: NOTE: NOTE:
Before assigning routes, patterns must be assigned to non-local
extensions, which is part of the numbering of the extensions. To perform
this procedure, see "Non-Local Dial Plan Extension Ranges" on page 3–19.
This section contains programming procedures for the following UDP Routing
features:
UDP Pool Routing
Facility Restriction Level (FRL)
Digit Absorption
Other Digits
Voice and/or Data Routing
!
SECURITY ALERT
Do not include the ARS codes of non-local systems in the non-local dial
plan, or calling restrictions may be violated.
:
