4 Common Administrative Procedures
Automatic Route Selection
Local Users Calling out on Networked Lines
To implement this operation on a local system where callers will use the trunks on
a remote system, use the procedures outlined in this section. The relevant topics
provide additional details.
1. Assign the networked tandem tie and/or PRI trunks to a pool or pools
including only those types of trunks. See
page 72.
2. Use one or more ARS tables for routing calls. Typically, you might need an
area code table. For example, if the remote system is in the 617 area code
and your local system is in the 908 area code, the area code table that you
set up might include the entry
upon how users in your system will employ networked lines. At the remote
system, ARS can be used, if necessary, to route the call to yet another
networked system. See
3. Set up the subpatterns for the table. In doing so, you may wish to check
with the remote system manager to ensure that routing will stipulate the
most cost-effective timing based on the rates at the remote location. If the
remote system is in a different time zone from your own, you may need to
take this into consideration as well. See
Subpatterns" on page 370.
4. Assign each tandem and/or tie trunk pool to an ARS table. See
Routing" on page 374.
5. Assign appropriate Facility Restriction Levels to the routes and to the
extensions that will use the networked lines. Factory settings restrict toll
calls. See
Level For Extensions" on page 3–108 respectively.
6. Assign absorbed and other (added) digits as required at both ends of the
connection. The local ARS feature adds (prepends) the ARS access code
of the remote system. At the remote system digit absorption may be
needed. For example, if local callers are in the 908 area code but the
networked lines are connected to a system in the 617 area code, callers
might dial  , where is the local ARS access code. At the
remote system, because the call would be a local call, the absorbed digits
would be
"Other Digits" on page –387
!
SECURITY ALERT
In Release 6.0 and later systems, do not place remote ARS access codes in
the non-local dial plan by specifying, for example, a non-local extension
range as 9000–9050 when the remote ARS access code is 9. Doing so
allows DID callers to make outside calls through the remote switch.
"ARS Tables" on page 367.
"Facility Restriction Level" on page –378
. See the ARS topics,
for additional information.
:
4
"Trunks to Pools Assignment" on
. The type of table required depends
"Start and Stop Times for
and "ARS Restriction
"Digit Absorption" on page –382
