Lucent Technologies MERLIN LEGEND Release 6.0 System Programming Manual page 816

MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
4 Common Administrative Procedures
Remote Access Features
ARS Facility Restriction Level (Hybrid/PBX only). Allows or disallows use
of outgoing trunks by assigning a facility restriction level from 0 through 6.
The FRL ranges from 0 (most restrictive) to 6 (least restrictive). The FRL
value assigned here is the opposite of the FRL value assigned to the ARS
route, where a value of 0 is the least restrictive and a value of 6 is the most
restrictive.
Allowed Lists Assignment. Assigns Allowed Lists and is used when
remote access users are restricted from making local or toll calls.
Disallowed Lists Assignment. Assigns Disallowed Lists and is used
when remote access users are not restricted from making local or toll calls.
A maximum of eight Allowed or Disallowed Lists can be assigned to lines/trunks.
Class of restriction settings are assigned either to all non-tie trunks or to all tie
trunks and DID trunks. They cannot be assigned to each trunk on an individual
basis.
Summary: Remote Access without Barrier Codes
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure To change calling restrictions:
System Manager
All
Not required
Form 3a, Incoming Trunks: Remote Access
Call restriction: Outward restricted
ARS restriction level: 3
Unrestricted, Toll Restricted, Outward Restricted; 0 to 6
No
No
Select restriction
To change ARS Facility Restriction Level:
Drop Dial FRL value
To assign/remove Allowed Lists:
Dial list no.
4
or
or
or
Issue 1
February 1998
Page 4-346
