4 Common Administrative Procedures
Automatic Route Selection
ARS Tables
Use this procedure for the following tasks:
To specify type of table (6-digit, area code, exchange,
or 1 + 7-digit number)
To add or change area codes to be included in each table
To add or change exchanges to be included in each table
A maximum of 16 tables can be established, numbered 1 through 16. Each table
can have a maximum of 100 entries, numbered 1 through 100. Tables 17 and 18,
the Default Toll and Default Local tables respectively, cannot be changed.
The first entry in a 6-digit table must be the area code. Subsequent entries consist
of exchanges within that area code.
Area code tables can contain only area codes. In Release 6.0 and later systems,
these tables are often used to provide cost-efficient calling through networked
lines/trunks connected to another system. The type of table required depends
upon how users in the networked systems will employ networked lines. When you
use ARS in this way, the ARS access code is only permitted on private trunks and
is blocked from calls that arrive from the public switched network.
Exchange and 1 + 7-digit tables can contain only exchanges.
The wildcard character (Pause) cannot be used to enter area codes or exchanges
in ARS tables.
Summary: ARS Tables
Programmable by. System Manager
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
Hybrid/PBX
Not required
Form 3f, Automatic Route Selection Tables
Not applicable
Not applicable
Yes
No
Specify table type
Drop Dial no.
4
4
Dial table no.
Dial entry no.
Issue 1
February 1998
Page 4-367
