Maintenance
Changing the scanner lamp
Caution!
The lamp and the lamphouse get very hot.
− Push the lamphouse cover a little to the front
until it opens and the lamp is switched off.
− Wait a few minutes to allow for the lamp to
cool down.
− The lamphouse lid opens to the front.
It locks into the rods of the holder.
Caution!
Do not bypass the lamp switch when the lamp
fitting is folded up. The light falling straight down
will damage the filter holder.
− The lamp fitting (1) is kept in the holder by
magnets. Pull the lamp fitting (1) out of the
holder and take out the old lamp with a clean
cloth.
− Check the lamp socket (2):
If the lamp socket or the contacts show any
discoloring caused by heat, this indicates
contact problems that may have a negative
effect on the print result. If necessary, have the
lamp socket replaced by a service technician.
8.24
2003-06-01 /PN 9008
Operation
dlabr070
dlabr071
dlabr072
AGFA d-lab.3
