Production
Loading Image Files from Data Carriers
Image files loaded from data carriers are
combined in an order.
The image files can be loaded from data carriers
or from a shared folder of a workstation connected
to the d-lab (see also Register 4 Digital orders,
Settings).
The single images of the order can be edited on
the d-lab and printed at once. Or else the selection
list can be saved and printed later.
– Call up:
Print mode
File print
When the screen is called up, the defined
standard configuration is automatically set.
– Touch the drive symbol:
1. Floppy disk
2. CD-ROM
3. Zip
4. Folder of a Workstation
5. Card Readers:
PCM: PCMCIA
CF: Compact Flash
SM: Smart Media
MS: Sony Memory Stick
SD: SD Memory Card
– If required, select the directory and the sub-
directory:
Transfer the files in the current (sub-) directory
to the previous screen with OK.
– The files available on the selected drive /
directory are displayed (see Figure above).
Select the files:
− Add all (double arrow) or mark single
frames and add (arrow).
− On the other hand, all / individual files can
be removed again from the selection list.
− To enter all image files of an order in the
selection list, select other media /
directories one after the other and add the
desired files, if any.
If files with the same name are included in
the list, they are numbered continuously,
e.g. tower, tower-2, tower-3.
6.44
2003-06-01 /PN 9008
Operation
042
094
AGFA d-lab.3
