Operation
Paper Processor, dryer
The filter (1) is located on the right side of the
densitometer at the back of the machine. The
filter cover is secured by 2 holding magnets and
can be removed without a tool.
The air filters (2) and (3) are mounted in holders
of perforated metal. To remove the holder, lift it
by the handle and pull it out to the front.
Order no.:
(1) CL+P3-E0898
(2) CL+P4-3812
(3) CL+P4-3812
− Blow out the air filters from the inside with
compressed air, or wash them in warm water if
they are very dirty.
− Replace very dirty air filters
− Place the air filter in the holder and insert the
holder again.
AGFA d-lab.3
Maintenance
2003-06-01 /PN 9008
dlabr073
8.23
