Warning code
Warning clear
Speed rate
Note:
If an recoverable error occurred in the positioning unit RTEX, click [Error Clear] to clear the error.
If a warning occurred in the positioning unit RTEX, click [Warning Clear] to clear the warning.
2. Click the JOG[+] for the JOG operation in the forward rotation. Click the JOG[-] for the JOG
operation in the reverse rotation.
3. Click [Current value update] to change the current value.
The following dialog box is displayed. Enter the current value to be changed.
The value can be changed during the JOG operation as well.
4. Click [Close] to close the dialog.
Note:
This dialog cannot be closed during the JOG operation.
7-46
Indicate the latest warning code when a warning occurs.
Clear the warning by clicking this button, when a warning occurred.
The target speed of the home return specified in the parameter settings for
each axis is regarded as 100%, and the operation is executed in the
specified speed rate.
Clicking [Speed rate] shows the dialog for inputting the value.
The speed rate changed here is effective only in the tool operation, and it
changes to the original speed rate automatically once the tool operation
quits.
