17.4.5 Synchronous Group Setting Area
For the synchronous operation, one slave axis is set for one master axis. Up to two groups can be set.
Offset
Bank Name
address
Synchronous
group 1
0B7H
Synchronous
mode
Synchronous
0B8H
group 1
Master axis
Synchronous
0B9H
group 1
Slave axis
00H
Synchronous
group 2
0BAH
Synchronous
mode
Synchronous
0BBH
group 2
Master axis
Synchronous
0BCH
group 2
Slave axis
17-16
Descriptions
Sets the operation mode of the synchronous operation.
00H: Synchronous mode A
Turn on the corresponding bit for the axes to be the master and slave axes
in the synchronous operation.
Each synchronous axis can be set for only one axis.
Bit Name
0 Synchronous attribute of axis 1
1 Synchronous attribute of axis 2
2 Synchronous attribute of axis 3
3 Synchronous attribute of axis 4
4 Synchronous attribute of axis 5
5 Synchronous attribute of axis 6
6 Synchronous attribute of axis 7
7 Synchronous attribute of axis 8
15 to 8 -
Sets the operation mode of the synchronous operation.
00H: Synchronous mode A
Turn on the corresponding bit for the axes to be the master and slave axes
in the synchronous operation.
Each synchronous axis can be set for only one axis.
Bit Name
0 Synchronous attribute of axis 1
1 Synchronous attribute of axis 2
2 Synchronous attribute of axis 3
3 Synchronous attribute of axis 4
4 Synchronous attribute of axis 5
5 Synchronous attribute of axis 6
6 Synchronous attribute of axis 7
7 Synchronous attribute of axis 8
15 to 8 -
01H: Synchronous mode B
Default Description
0 0: Not execute synchronous
operation.
0
1: Synchronous operation
0
master/slave axis setting of
0
group
0
0
0
0
- -
01H: Synchronous mode B
Default Description
0 0: Not execute synchronous
operation.
0
1: Synchronous operation
0
master/slave axis setting of
0
group
0
0
0
0
- -
