7.14.2
D ownloading Setting Data to Positioning Unit RTEX
1 1 3 B
Transfer the setting parameters and positioning data to the positioning unit RTEX.
1. Make the connection between a PC and PLC, and configure the settings. Then, select [File] →
[Download to Unit] in the menu bar, or click the [Download to Unit] icon in the toolbar.
The dialog is shown as below.
Connect to
Select slot
Communication settings
2. Clicking [Yes] displays the following dialog.
7-34
Displays the slot number of a positioning unit RTEX to be transferred.
The slot number of a positioning unit RTEX to be transferred can be
changed.
Changes the communication setting.
