Pen set
For more information on Pen Sets, see 'Set pen parameters' on page 135.
Change the pen set
Open the job that contains the desired drawings.
1
Double click on the Pen Set field of the drawing you want to change.
2
The Pen Set drop-down menu appears.
Select:
3
Select New Pen: You can select another already existing pen set, by
specifying its file name (*.pen).
View Current Pen: Opens the Pen Settings window. You can view the current
pen settings and make changes if desired.
Close the Pen set window to remove it.
4
Alignment
This option controls how your drawing is placed on the paper in relation to the
edges of the selected paper size. You can choose from one of the standard menu
options or set custom offset size.
Change the alignment
Open the job that contains the desired drawings.
1
Click with the right mouse button on the Alignment field of the drawing you
2
want to change.
The alignment drop-down menu appears.
Select the desired alignment setting:
3
One of the predefined alignment settings.
User size: The Imaging Properties window appears, to specify a custom
alignment
Click outside the drop-down menu to remove it.
4
Click OK when the Imaging Properties window is activated
5
Rotation and mirror
This option displays if and how the drawing is to be rotated on the paper. You
can either rotate the drawing or mirror the drawing horizontally.
Handling jobs
81
