View and position a drawing

You can use the viewer to see the result of adding stamps and overlays to a
drawing. It is also possible to change the position of a stamp or overlay, and
directly see the result in the View window.
View a drawing with added stamp or overlay
In the Job window, double click on the added stamp or overlay.
1
If you have added more than one stamp or overlay to a drawing,
Note:
double click on the last stamp or overlay to view the final result.
The View window will open to show you how the added stamp or overlay is
2
added to the drawing.
Example:
To view the final result of drawing1 together with Label1 and Overlay1 you
have to select Overlay1 and click the View button in the toolbar.
If you select Label1 and click the View button only drawing1 and Label1 will
be viewed.
If you select drawing1 and click the View button only drawing1 will be
viewed.
Define Stamps and Overlays
Consider the following job window:
157
